Joining tungsten with steel for DEMO: Simultaneous brazing by Cu-Ti amorphous foils and heat treatment

Дата
2021
Авторы
Svetogorov, R.
Bachurina, D.
Suchkov, A.
Gurova, J.
Savelyev, M.
Dzhumaev, P.
Kozlov, I.
Leont'eva-Smirnova, M.
Sevryukov, O.
Journal Title
Journal ISSN
Volume Title
Издатель
Научные группы
Организационные подразделения
Организационная единица
Институт ядерной физики и технологий
Цель ИЯФиТ и стратегия развития - создание и развитие научно-образовательного центра мирового уровня в области ядерной физики и технологий, радиационного материаловедения, физики элементарных частиц, астрофизики и космофизики.
Выпуск журнала
Аннотация
© 2020Development of a reliable technology to join tungsten with steel is essential for DEMO application; however, it is difficult due to large differences in their physical properties. To solve this problem, high-temperature brazing was carried out. Cu-Ti brazing alloys, which were rapidly solidified into foil, were used together with a compensating vanadium interlayer, so the EK-181 steel/Cu-28Ti/V/Cu-50Ti/W and EK-181/Cu-50Ti/V/Cu-50Ti/W brazed joints were obtained. The microstructures of the seams were investigated by optical microscopy, SEM (EDX, EBSD) and synchrotron XRD. Thermocycling and shear strength tests showed that Cu-28Ti wt. % brazing alloy ensures a firmer joint compared to Cu-50Ti wt. %. The Cu-28Ti wt. % brazing alloy was used to perform high-temperature brazing in the brazing mode equivalent to traditional EK-181 steel heat treatment. It showed that every step of the heat treatment affected the microstructures and the shear strength.
Описание
Ключевые слова
Цитирование
Joining tungsten with steel for DEMO: Simultaneous brazing by Cu-Ti amorphous foils and heat treatment / Svetogorov, R. [et al.] // Fusion Engineering and Design. - 2021. - 10.1016/j.fusengdes.2020.112099
